33% Off
Philmac

Philmac 25mm x 1" Metric Poly x FI BSP 90 Degree Pipe Elbow - PN16 Underground Rated

$19.20 $28.81 -33% OFF
You save: $9.61
Price reduced — was $28.81
Only 5 left!
Qty:
14-Day Change-of-Mind Returns
Secure Checkout
Australian Stock
Dispatches within 1-2 business days Australia-wide delivery, typically 2-10 business days
Australian Stock Ships from AU warehouses
We accept:American Express Apple Pay Google Pay Mastercard PayPal Shop Pay Union Pay Visa

Frequently bought together

The Philmac 25mm x 1" Metric Poly x FI BSP Pipe Elbow turns a metric poly run through 90 degrees to a threaded female outlet.

  • Connection: 25mm metric poly to 1" female BSP (FI)
  • Bend: 90 degrees
  • Material: Polypropylene body, acetal nuts
  • Rating: PN16 (1600 kPa max working pressure)
  • Underground rated: Yes

Turns 25mm metric poly pipe around a right angle to a 1" threaded fitting on Blue Line and similar pressure pipe. Underground rated for buried runs.

More about this product

Philmac 25mm x 1 Poly Pipe Elbow - Polypropylene - 90 Degree - PN16 is a robust fitting designed for use with Blue Line Poly Pipe, ensuring reliable connections in various applications.

The Philmac 25mm x 1 Poly Pipe Elbow is engineered for durability and ease of use in underground applications. This 90-degree elbow fitting features a unique design where the collet and seal remain captive in the body when the nut is removed, preventing loose components. It incorporates the innovative Slide and Tighten technology, making installation straightforward and efficient. The fitting is compatible with Rural, 2G Metric, and 3G Metric connection components, allowing for versatile use across different systems. Designed and manufactured in Australia, this fitting meets the PN16 rating, ensuring it can handle a maximum working pressure of 1600 kPa.

Features

  • No loose components; collet and seal remain captive when the nut is removed.
  • Incorporates Slide and Tighten technology for easy installation.
  • Compact and robust PN16 fitting suitable for various applications.
  • Easy disassembly for maintenance and adjustments.
  • Interchangeable with Rural, 2G Metric, and 3G Metric connection components.

Specifications

Dimensions (W x H x D) 65mm x 90mm x 65mm
Weight 55g
Material Polypropylene Body, Acetal Nuts
Colour Black
Model Number 70763300
Bend Degree 90
Maximum Working Pressure 1600 kPa
Compatible Pipe Material Metric polyethylene pressure pipe

The Philmac 25mm x 1 Poly Pipe Elbow - Polypropylene - 90 Degree - PN16 is designed for reliable connections in plumbing systems.

Questions & Answers

What does it connect?

25mm metric poly pipe to a 1" female BSP thread, at a 90-degree bend.

What pressure is it rated to?

PN16, up to 1600 kPa maximum working pressure.
