Simplecom HDMI 2.0 to USB 4K@60Hz Video Capture Card, Stream & Record 4K 60FPS

Capture and stream your content in ultra-high definition with the Simplecom HDMI 2.0 to USB Video Capture Card.

Simplecom HDMI 2.0 to USB Video Capture Card

This device is designed for gamers, streamers, and content creators, supporting HDMI 2.0 input and passthrough with HDR10 and Variable Refresh Rate (VRR). It delivers stunning video capture and streaming up to 4K@60Hz, 2K@144Hz, and 1080p@240Hz, perfect for high-quality recording.

Key Features & Benefits

• True 4K 60FPS HDMI 2.0 to USB video capture card
• Supports video capture or streaming up to 4K@60Hz, 2K@144hz, 1080p@240Hz
• Supports video passthrough up to 4K@60Hz, 2K@144hz, 1080p@240Hz
• 3.5mm microphone jack for commentary input while recording or streaming
• 3.5mm AUX output for monitoring audio from video source
• VRR (Variable Refresh Rate) technology ensures a smooth gaming experience
• USB 3.2 Gen 2 host interface supports data transfer rates up to 10Gbps
• USB-C and USB-A combo cable, convenient for use on different computers
• Compliant with UVC (USB Video Class) and UAC (USB Audio Class)
• Compatible with most mainstream capture software, such as VLC, OBS, etc.
• Ideal for recording or streaming from game consoles, cameras, video players and more
• Powered by USB host, no external power supply required
• Plug and Play, no driver installation is required
• Durable and stylish aluminium alloy housing
• Works with Windows 10 or later, macOS 10.12 or later

Specifications

• Host Interface: USB-C USB 3.2 Gen 2 10Gbps (plug and play, UVC)
• HDMI Input: HDMI 2.0 (unencrypted), backward compatible
• HDMI Output (Passthrough): HDMI 2.0 (HDR10, VRR are supported)
• Mic Input: 3.5 mm Line In (3-Pole)
• AUX Output: 3.5 mm Line Out (3-Pole)
• Video Format Support: MJPEG, YUY2, NV12, I420
• Resolution and Frame Rate Support by Video Format:
  MJPEG: up to 4K@60Hz, 2K@144Hz, 1080p@240Hz
  YUY2 (4:2:2): up to 2K@60Hz, 1080p@60Hz
  NV12 (4:2:0): up to 4K@30Hz, 2K@60Hz, 1080p@120Hz
  i420 (4:2:0): up to 4K@30Hz, 2K@60Hz, 1080p@120Hz
• Audio Format Support: LPCM
• HDCP Support: HDCP2.3 Passthrough
• Operating temperature range: -10°C to 55°C
• Housing Material: Aluminium alloy
• Dimensions: 9.2 x 6.3 x 1.5CM (L x W x H)
• Weight: 81g approx.
• Compatible Recording Software: OBS, PotPlayer, VLC, vMix etc.
• Operating System Support: Windows 10 or later, macOS 10.12 or later

Package Includes / What's in the Box

• 4K USB Video Capture Card
• USB-C to USB-C and USB-A combo cable
• HDMI Cable

Important Notes

• Please connect the device to a USB 3.0, USB 3.2 (5Gbps/10Gbps) port on your computer. USB 2.0 ports are not supported.
• To ensure optimal video capture quality, use the original USB-C cable included in the box, or a USB-C cable that supports 5Gbps or 10Gbps data transfer. Some USB-C cables only support USB 2.0 speeds and are not suitable for this device.
• For stable high-resolution video transmission, please use High-Speed HDMI cables with 18Gbps bandwidth. The HDMI cables should be shorter than 3 meters to ensure reliable connection.
• Video recording quality depends not only on resolution and frame rate, but also on the bitrate setting. To achieve good quality video at high resolutions, you'll need to increase the bitrate in software setting accordingly.

Enjoy seamless video capture and streaming with the Simplecom HDMI 2.0 to USB Video Capture Card.
